Medium Efficiency F5 - F9 Pocket Air Filter Synthetic Fiber Material

I'm Online Chat Now

Medium Efficiency F5 - F9 Pocket Air Filter Synthetic Fiber Material

China Medium Efficiency F5 - F9  Pocket Air Filter Synthetic Fiber Material supplier
Medium Efficiency F5 - F9  Pocket Air Filter Synthetic Fiber Material supplier Medium Efficiency F5 - F9  Pocket Air Filter Synthetic Fiber Material supplier

Large Image :  Medium Efficiency F5 - F9 Pocket Air Filter Synthetic Fiber Material

Product Details:

Place of Origin: China
Brand Name: No or OEM
Certification: ISO, CE
Model Number: Standard

Payment & Shipping Terms:

Minimum Order Quantity: 50 Pcs
Packaging Details: 5-6 pcs in one cardboard box. sea-worthy or as request
Delivery Time: 20 days after receive deposit
Payment Terms: T/T, Western Union
Supply Ability: 500 Piece/Pieces per Week
Contact Now
Detailed Product Description
Condition:: New Efficiency: F5-F9
Medium Material: Fiberglass Porosity: 0.3u
Construction: Bag Filter Weight: According To Different Size
Size: As Per Request Color: According To Different Class
Supply Ability: 500 Piece/Pieces Per Week

Synthetic Fiber Material Medium Efficiency F5-F9 Bag/Pocket Air Filter





Principle Vacuum filtration Use: Air filtration
Style: Bag Performance: Precision filtration
Suitable Air Nature High hygiene requirements
Material Fiber Brand OEM
Type New Application Chemical, pharmaceutical, automotive, light industry, food
Weight Standard Size Standard





Description



The bag filter features a non-carcinogenic, microfiber polypropylene media that resists moisture, microbial growth and abrasion; because it is synthetic, the filter media will not shed glass particles into the filtration system

This bag filter is made from a galvanized metal frame with internal pocket support retainers; they are 100% synthetic polypropylene media with sonically sealed pocket edges, ends and flutes

Bag filters are cost-effective and economical solution for high efficiency filtration; best suited for offices, airports, paint booths,



Application



It can be used for the intermediate filtration of the air conditioning system to protect the lower-stage filter and the system itself in the system. In places where the air purification and cleanliness requirements are not strict, the air treated by the medium-efficiency filter can be directly sent to the user. The aluminum frame bag filter adopts high-quality synthetic fiber or imported glass fiber as the filter material, aluminum alloy profile frame and internal sprayed cold wire drawing support frame.



Replacement cycle



Under the rated air volume conditions, the filter needs to be replaced within 3-4 months; or when the resistance of the filter reaches 400Pa or more, the filter must be replaced; if the filter uses a cleanable filter material, replace it. The filter material can be rinsed with water or a solution containing a neutral detergent, dried and then replaced; at most it can be washed twice, that is, a new filter must be replaced; if the dust concentration in the environment is large, this is The life cycle will also decrease.



Size



Model



Outside Dimensions

(mm)



Rated air flow

(m3/h)

Resistance



Efficiency

(class)

Color Pockets
JJ-MD53

495×295×500mm

20″×12″×20″

1000m3/h

50Pa F5

55Pa F6

60Pa F7

65Pa F8

70Pa F9





40-50% F5

60-70% F6

75-85% F7

85-95% F8

95- 98% F9





White

Orange

Green

Pink

Yellow

5
JJ-MID55

495×495×500mm

20″×20″×20″

1800m3/h 5
JJ-MID63

595×295×500mm

24″×12″×20″

1300m3/h 6
JJ-MID65

595×495×500mm

24″×20″×20″

2200m3/h 6
JJ-MID66

595×595×500mm

24″×24″×20″

2600m3/h 8
JJ-MID53

495×295×600mm

20″×12″×24″

1200m3/h 5
JJ-MID55

495×495×600mm

20″×20″×24″

2200m3/h 5
JJ-MID63

595×295×600mm

24″×12″×24″

1600m3/h 6
JJ-MID65

595×495×600mm

24″×20″×24″

2700m3/h 6
JJ-MID66

595×595×600mm

24″×24″×24″

3200m3/h 8



Medium Efficiency F5 - F9  Pocket Air Filter Synthetic Fiber Material
