Product Details:
Payment & Shipping Terms:
|
Filter Length: | 600mm | Filter Diameter: | 145mm |
---|---|---|---|
Carbon Bed Depth: | 26mm | Filter Mesh: | 53% Open Area |
Carbon Packing: | Vibro Machine | Anti Static Treatment: | Yes |
High Light: | filter cylinder,carbon canister air filter |
1. Application for ventilation of airport, railway station, metro, commercial building, pharmaceutical, electrics, 2. chemical, food, beverage, kitchen oil smoke,
3. Common specification 145x450mm, 145x 600mm;
4. 145mm, 160mm diameter;
5. Virgin carbon pellet with IAV980;
6. 26mm-28mm carbon bed depth;
7. Filter mesh provide large filtration area;
8. Light weight and max air flow
9. Easy and fast installation
Model
|
Dimension (mm) |
Carbon layer thickness (mm) |
Carbon content (kg) |
Total weight (kg) |
resistance@air volume (Pa@m3/h) |
Diameter x Length | |||||
JJCF-330 | Ф145×330 | 28.5 | 1.37 | 3.27 | 135@225 |
JJCF-405 | Ф145×405 | 28.5 | 1.72 | 3.82 | 110@225 |
JJCF-450 | Ф145×450 | 28.5 | 1.88 | 4.08 | 100@225 |
JJCF-480 | Ф145×480 | 28.5 | 2.1 | 4.5 | 90@225 |
JJCF-500 | Ф145×500 | 28.5 | 4.6 | 5.1 | 85@225 |
JJCF-600 | Ф145×600 | 28.5 | 2.5 | 5.2 | 70@225 |
