145x450mm Alumina Chemical Carbon Filter Cartridge For Air / Gas 330mm 400mm Length

145x450mm Alumina Chemical Carbon Filter Cartridge For Air / Gas 330mm 400mm Length

145x450mm  Alumina Chemical  Carbon Filter Cartridge For Air / Gas 330mm 400mm Length
145x450mm  Alumina Chemical  Carbon Filter Cartridge For Air / Gas 330mm 400mm Length 145x450mm  Alumina Chemical  Carbon Filter Cartridge For Air / Gas 330mm 400mm Length

Large Image :  145x450mm Alumina Chemical Carbon Filter Cartridge For Air / Gas 330mm 400mm Length Get Best Price

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: IOS
Model Number: Φ145x330mm,Φ145x450mm,Φ145x6000mm
Payment & Shipping Terms:
Minimum Order Quantity: 50 pcs
Packaging Details: 4pc/carton
Delivery Time: 15 days
Payment Terms: T/T, Western Union
Supply Ability: 500pcs/day
Detailed Product Description
Material: Pellet Carbon Body: Galvanized Sheet
Diameter: 145mm Length: 330mm, 400mm, 600mm, Or Customized
Seal: Included Pack: 4pc/box
High Light:

carbon air filter fan

,

carbon canister air filter

145x450mm Activated Alumina Chemical Filter Cartridge For air/ gas





Description



145x450mm Activated alumina chemical filter cartridge for air/ gas is made of two raw material, half of activated carbon, half of Potassium permanganate impregnated activated alumina. The latter can remove hydrogen sulfide, mercaptan, ethylene, formaldehyde, SOx, NOx ... widely used for corrosion control in industrial environments, clean rooms, general air purification and elimination of ethylene to control fruit, vegetable ripening and flowers. Activated alumina chemical filter cartridge has more application than activated carbon filter cartridge.



145x450mm chemical filter cartridge by the same volume of high-quality activated carbon and activated carbon impregnated potassium permanganate made.Potassium permanganate evenly distributed in the ball on the inside and the surface, the color is purple and the air can be fully with the chemical reaction of the gas pollutants to generate non-toxic inorganic salt solids.





Packing:



4pcs/carton, separated by corrugated cardboard in the middle carton to prevent collisions with each other, Activated alumina chemical filter cartridge

can’t be damaged.



Application:



Commercial Building

Data center

Food and drinks

Health care

Guest House

Microelectronics

Museum and History Store

Pulp and paper

Refinery

School and university

Wastewater treatment

Waste management







Model



Dimension
(mm)
Carbon layer thickness
(mm)
Carbon content
(kg)
Total weight
(kg)

Resistance

@air volume
(Pa@m3/h)

Packing
Dia.×Length
HACT-330 Ф145×330 28.5 1.37 3.27 135@225 31*31*41.5
HACT-405 Ф145×405 28.5 1.72 3.82 110@225 31*31*49
HACT-450 Ф145×450 28.5 1.88 4.08 100@225 31*31*53.5
HACT-480 Ф145×480 28.5 2.1 4.5 90@225 31*31*56.5
HACT-500 Ф145×500 28.5 4.6 5.1 85@225 31*31*58.5
HACT-600 Ф145×600 28.5 6.5 5.2 70@225 31*31*68.5
