Product Details:
Payment & Shipping Terms:
|
| Type: | Cartridge | Diameter: | 145mm |
|---|---|---|---|
| Carbon Bed Depth: | 26mm | Filter Mesh: | 53% Open Area |
| IAV: | 950mg/g | CTC: | 60% |
| High Light: | filter cylinder,carbon air filter fan |
||
1. Common specification 145x450mm, 145x 600mm;
2. Ash 8%;
3. CTC 60%;
4. Application for airport, railway station, metro, commercial building, pharmaceutical, electrics, chemical, food, beverage, kitchen oil smoke,
5. Filter cartridge diameter as 145mm or 160mm;
6. Galvanized steel mesh provides large airflow;
|
Model
|
Dimension (mm) |
Carbon layer thickness (mm) |
Carbon content (kg) |
Total weight (kg) |
resistance@air volume (Pa@m3/h) |
| Diameter x Length | |||||
| JJCF-330 | Ф145×330 | 28.5 | 1.37 | 3.27 | 135@225 |
| JJCF-405 | Ф145×405 | 28.5 | 1.72 | 3.82 | 110@225 |
| JJCF-450 | Ф145×450 | 28.5 | 1.88 | 4.08 | 100@225 |
| JJCF-480 | Ф145×480 | 28.5 | 2.1 | 4.5 | 90@225 |
| JJCF-500 | Ф145×500 | 28.5 | 4.6 | 5.1 | 85@225 |
| JJCF-600 | Ф145×600 | 28.5 | 2.5 | 5.2 | 70@225 |
